Exceptional performance. Unique design.
Design, fabrication and components combine for very high performance. Every HTR Arctic patio door is tested under current standards and built in Canada to a strict quality spec.
Choose the right patio system for your opening
Standard Patio Doors
HTR Arctic Standard Patio Doors deliver quiet, smooth operation with upgraded North-American hardware, a standard twin locking system, and heavy-duty components built to last.
Quality and beauty in every component
Click any number to see why each component matters.
Standard features you'd usually pay extra for
Upgraded North-American hardware. Mix interior/exterior colours and add an exterior key lock.
Internal mini blinds available on 5F and 6F 79.5″H systems and equivalent glass sizes — tilt and lift.
Standard tempered Low-E with argon. Choose Low-E combinations for higher SHGC or improved U-value.
Smooth, robust latching with anti-locking device and heavy-duty hooks. Standard on every door.
Top-of-the-line North-American components on an anodized aluminum track — quiet for years.
Standard 1½″ aluminum screen with an optional 3″ Heavy Duty screen, custom colours and pet mesh.
Custom-sized engineered transoms and sidelights to fit the opening.
Internal grill patterns for a more sophisticated look or to match adjacent windows.
Standard Patio Doors — configurations
- Performance Class & Grade
- R – PG40
- Water Penetration Resistance
- 360 Pa (7.52 psf)
- Air Leakage
- A3 – 0.5 L/s/m²
- Design Pressure
- ±1920 Pa (±40 psf)
| Width | Heights |
|---|---|
| 58½″ | 79½″ |
| 59½″ | 79½″81½″95½″ |
| 70½″ | 79½″ |
| 71½″ | 79½″81½″95½″ |
| 95½″ | 79½″81½″95½″ |
HTR Arctic Stacking Patio Doors
Bring the outdoors in with a 6-panel or 3-panel stacking system — up to 204⅝″ wide with optional security glass.
Stock & standard finishes
Note: colours may vary slightly from those illustrated due to printing/display differences.
HTR Limited Warranty — one point of contact
All periods start when installation is completed. Coverage takes effect when paid in full. Transferable with written notice within 30 days of title transfer. Covered-item labour is included for that item's coverage period, up to 25 years. Full terms are in your signed contract.
| Component | Period | Notes |
|---|---|---|
| Installation workmanship | 25 years | Improper fit, air/water leakage caused by our installation, rough-opening insulation, exterior caulking and operation problems caused by our work. |
| Labour | 25 years | Labour to repair or replace any covered item, including removal, reinstallation and glass replacement, at no charge for that item's coverage period (up to 25 years). |
| Patio door vinyl frame & sash | 25 years | Patio door vinyl frame and sash coverage. |
| Sealed glass units | 25 years | Against seal failure (fogging/moisture between panes). Surface condensation is not seal failure. |
| Patio door rollers & locks | 10 years | Patio door rollers and locks coverage. |
| Bug screens | 5 years | Bug screen coverage. |
| Painted finishes | 10 years | Painted finish coverage. |
Ready to plan your patio door?
We'll measure your opening, recommend the right configuration and finish, and quote it on the spot.
